Set up a compatible 2014-2018 Jeep Cherokee Trailhawk for flat towing with this Blue Ox BX1155 baseplate. The vehicle-specific design provides attachment points for a Blue Ox tow bar and includes removable tabs for a cleaner look when not towing.
The Blue Ox BX1155 baseplate is designed for 2014-2018 Jeep Cherokee Trailhawk models with Adaptive Cruise Control and a 2-speed transfer case. It provides the frame-mounted connection points needed to attach a compatible Blue Ox tow bar for dinghy towing behind a motorhome.
This baseplate features removable attachment tabs that twist and lock into place for towing, then remove when not in use. The kit includes the baseplate components, removable tab assemblies, electrical mounting bracket, permanent safety cables, quicklinks, cap plugs, and required installation hardware.
Designed for 2014-2018 Jeep Cherokee Trailhawk models with ACC
Provides attachment points for compatible Blue Ox tow bars
Tabs twist and lock for towing, then remove when not in use
Includes baseplate hardware, safety cables, quicklinks, and brackets
Fits 2014-2018 Jeep Cherokee Trailhawk models with Adaptive Cruise Control and a 2-speed transfer case. Confirm the vehicle year, trim, transfer case, front fascia, tow bar compatibility, and flat towing requirements before ordering.
1. Confirm Vehicle: Verify the Jeep year, Trailhawk trim, Adaptive Cruise Control, and 2-speed transfer case before installation. 2. Remove Fascia: The fascia cover and fascia must be removed and reinstalled during baseplate installation. 3. Remove Tow Hooks: Factory tow hooks are removed during installation and are not reinstalled. 4. Drill and Trim: Some drilling and trimming is required for proper fitment and electrical/breakaway bracket placement. 5. Final Check: Confirm tow bar tab width compatibility, torque all hardware to Blue Ox instructions, and test the complete flat towing setup before travel.
Blue Ox BX1155 baseplate assemblies Removable attachment tab assemblies Electrical mounting bracket Electrical bracket Class IV permanent baseplate safety cables Quicklinks Black cap plug receivers Installation hardware
Blue Ox Customer Care: Phone: 800-228-9289 Phone: 402-385-3051 Website: blueox.com For fitment help, confirm the Jeep Cherokee year, Trailhawk trim, Adaptive Cruise Control, 2-speed transfer case, front fascia, and tow bar model before ordering.
