Professional-grade 8-roller cast iron pump for maximum-volume agricultural and field spraying applications. 24.5 GPM, 150 PSI, counter-clockwise rotation, 15/16" shaft.
The Remco R880C is the highest-output cast iron pump in the RollMax Series, delivering up to 24.5 GPM through its 8-roller design — the most powerful configuration Remco offers in this line. Built with a rugged cast iron body, the R880C is engineered for demanding PTO-driven sprayer applications where maximum flow volume and proven durability are the top priorities, making it the right choice for large-acreage operations running water and low-corrosive liquids.
The R880C runs on a larger 15/16" shaft with 1" FNPT ports to accommodate the higher flow demands of heavy-duty PTO sprayer rigs. Like all RollMax pumps, it's built on Remco's Rebuild Ready platform — fully serviceable in the field in minutes with nothing more than a wrench, without touching the drive shaft or plumbing. The R880C is also available as the R880C-TAK kit, bundled with a torque arm, chain, and multi-speed coupler for a complete ready-to-mount PTO package.
The highest-output RollMax model — 8-roller design delivers maximum volume for large-scale PTO sprayer operations
Heavy-duty cast iron body engineered for the rigors of demanding, high-volume agricultural field use
Full field serviceability in minutes with only a wrench — shaft and plumbing stay connected throughout
R880C-TAK bundles the pump with torque arm, chain, and multi-speed coupler for a complete PTO solution
The R880C stays mounted to the drive shaft and plumbing throughout the entire rebuild process. All you need is a wrench: Step 1: Loosen and remove the 4 cap bolts Step 2: Slide the pump's endplate off the shaft carefully Step 3: Inspect and replace worn rollers using the R880RK repair kit; lubricate shaft seal before reinstalling Step 4: Reinstall the endplate and cap bolts Step 5: RollMax is ready to spray Keep the R880RK Universal Repair Kit on hand for fast, no-downtime field rebuilds.
Repair Kit: • R880RK — Universal Repair Kit: 8 Max Rollers (3/4"), Needle Bearing, 2 Lip Seals, O-Ring, Pill Key Coupler: • RMC151651 — 15/16" Shaft, 540/1000 RPM Multi-Speed, Cast Aluminum/Zinc, Set Screws Rotation Prevention: • RMTAC — Torque Bar and Chain (rotation prevention for PTO-mounted pumps) Complete Kit Option: • R880C-TAK — Includes R880C pump, torque arm, chain, and RMC151651 multi-speed coupler
📥 Download the RollMax Operation Manual (PDF) The manual covers installation, operation, maintenance, and rebuild procedures for the full RollMax pump series including the R880C. Technical Support: Remco Industries Website: remcoindustries.com
The R880C is configured for Counter-Clockwise (CCW) rotation only. Confirm your PTO drive shaft rotation direction before installation. Running the pump in the wrong direction will result in poor performance and accelerated wear. Use of the RMTAC Torque Bar and Chain is recommended to prevent pump rotation on PTO-mounted installations.
