B&W Hitches TS10065BMP Tow & Stow Dual Ball Mount -- 2" and 2-5/16" Balls -- 5" Drop -- 35 lbs

B&W Hitches TS10065BMP Tow & Stow adjustable dual ball mount with 2-inch and 2-5/16-inch balls and 5-inch drop for 2-inch receiver hitches

Alternative Views:


: $379.00
Part Number: TS10065BMP
Manufacturer: B&W Hitches

Quantity in Stock :38

Free Shipping
Availability: In Stock
Qty:


B&W Hitches Dual Ball -- 2" & 2-5/16" 5" Drop B&W Tow & Stow TS10065BMP -- The Only Ball Mount You Need in the Truck

Stop swapping ball mounts every time you change trailers. The B&W Hitches Tow & Stow TS10065BMP puts both a 2-inch ball and a 2-5/16-inch ball on a single removable mount with a clean 5-inch drop, so you can flip or adjust on the fly and stay ready for whatever is hitched up next -- travel trailer, fifth-wheel pin box dolly, boat, or car hauler.

Two Balls, One Mount, Zero Compromises

The Tow & Stow line is B&W's answer to the drawer full of single-ball mounts that every serious tower accumulates. The TS10065BMP carries the two most common trailer ball sizes in RV and towing -- the 2-inch ball used on most travel trailers and the 2-5/16-inch ball required for heavier fifth-wheel pin box dollies, gooseneck adapters, and larger conventional trailers -- on a single forged-steel shank that locks into any standard 2-inch receiver tube.

The 5-inch drop is the sweet spot for full-size trucks and taller SUVs towing trailers with couplers that sit lower than the receiver tube. If you run a lifted truck or need rise instead of drop, B&W offers the same TS10065 head on mounts with different drop/rise combinations -- but for most stock-height half-tons and three-quarter-tons pulling level, 5 inches down is the right call.

Dual Ball Head

2-inch and 2-5/16-inch chrome balls are both mounted and ready. No swapping, no loose hardware to lose on the road.

Adjustable Drop/Rise

The head pivots and pins at the 5-inch drop position, and can be repositioned for rise when the tow vehicle setup changes.

Forged and Powder-Coated

Black powder-coat finish over forged steel resists rust and road grime without the chrome-flaking issues common on cheaper mounts.

Standard 2" Receiver Fit

Shank slides into any standard 2-inch square receiver tube. Secured with a standard hitch pin -- pin and clip included.

Who This Mount Is Built For

If you tow more than one trailer -- a travel trailer with a 2-inch ball coupler and a heavier unit needing a 2-5/16-inch ball, or if your tow vehicle pulls a horse trailer on weekends and a fifth-wheel dolly on camping trips -- this mount eliminates the need to carry extras. Full-timers who move frequently and boondockers who tow utility trailers to remote sites find the flip-and-go convenience genuinely useful at the campground when unhooking and rehooking the same day.

It is also a practical match for RV service technicians and dealers who need one mount that handles a wide mix of incoming trailers without digging through a bin for the right ball.

Tow & Stow Series Advantage: The locking head design means the unused ball tucks up and out of the way -- it does not hang below the active ball and create a trip hazard or ground-clearance problem when backing into tight campsites.

Drop vs. Rise -- Getting the Trailer Level

A level trailer tows better, brakes better, and puts less stress on the coupler and hitch. Here is the quick field check:

  • Measure the height of your receiver tube opening from the ground.
  • Measure the height of your trailer coupler from the ground when the trailer is loaded and sitting level.
  • If the receiver is higher than the coupler, you need drop. If the receiver is lower, you need rise.
  • Most stock-height half-ton and three-quarter-ton trucks with a 2-inch receiver tube opening at 18-20 inches need 4-6 inches of drop to match a standard travel trailer coupler at 14-16 inches.

The 5-inch drop on the TS10065BMP falls right in the middle of that common range, making it a strong default choice before you measure and confirm.

Within the Tow & Stow Family: B&W offers the dual-ball Tow & Stow head with 3-inch, 4-inch, 5-inch, 6-inch, and 7-inch drop/rise options. The TS10065BMP is the 5-inch drop version. If your rig needs a different drop measurement, look for the corresponding TS100xx part number in the same series.

Installation and Use Notes

Installation is straightforward -- slide the shank into the receiver tube, align the hitch pin hole, insert the included pin, and secure the clip. Before each tow:

  • Confirm the correct ball (2-inch or 2-5/16-inch) is positioned and locked in the active towing position.
  • Verify the coupler locks fully onto the ball and the coupler latch is secured.
  • Attach safety chains per your trailer's requirements.
  • Check that all trailer lights are functioning before pulling out.
Maintenance Tip: Periodically inspect the pivot pin and locking mechanism for wear or corrosion, especially after towing in wet or salted-road conditions. A light coat of grease on the shank and pivot point keeps the adjustment smooth season after season.
Weight Rating Heads-Up: Always verify the gross trailer weight (GTW) and tongue weight (TW) ratings of this mount against both your trailer's actual weight and your tow vehicle's hitch receiver rating. The limiting rating is always the lowest-rated component in the chain -- tow vehicle, receiver, ball mount, or coupler.
Consider Pairing With: A receiver hitch lock or coupler lock for campsite security. B&W Tow & Stow mounts accept standard 5/8-inch receiver hitch locks that replace the standard pin.

Physical Specifications

Manufacturer Part NumberTS10065BMP
UPC843233006438
Weight (as shipped)35.0 lbs
Dimensions (L x W x H)16.87" x 12.0" x 8.87"
FinishBlack powder coat over forged steel

Hitch Specifications

Receiver Size (Shank)2" square
Ball 1 Diameter2"
Ball 2 Diameter2-5/16"
Drop5"
Ball Mount StyleDual ball, adjustable head (Tow & Stow)
Hitch Pin Diameter5/8" (standard)

Compatibility

Receiver Tube RequiredStandard 2" square receiver hitch
Typical Tow Vehicle FitFull-size half-ton and three-quarter-ton trucks (stock ride height), SUVs with 2" receiver
Trailer Coupler Sizes Served2" ball coupler, 2-5/16" ball coupler
Common Trailer ApplicationsTravel trailers, fifth-wheel pin box dollies, boat trailers, horse trailers, car haulers, utility trailers
SeriesB&W Tow & Stow

B&W Tow & Stow Series Context

TS10065BMPDual ball (2" and 2-5/16"), 5" drop -- this item
Other Drop Options (same head)3", 4", 6", 7" drop/rise variants available in TS100xx series
Single Ball VariantsB&W also offers Tow & Stow mounts with single adjustable balls for applications needing one size only

In the Box

Ball Mount Shank and HeadIncluded -- assembled
2" Chrome BallIncluded -- pre-installed
2-5/16" Chrome BallIncluded -- pre-installed
Hitch Pin and ClipIncluded
Separate Wiring HarnessNot included
Weight Distribution ComponentsNot included -- this is a standard ball mount, not a WD system
Important Information -- Read Before Towing
  • Always confirm the gross trailer weight (GTW) and tongue weight (TW) of your loaded trailer do not exceed the rated capacity of this mount, your tow vehicle's receiver hitch, and the tow vehicle manufacturer's towing limits. The lowest-rated component governs the safe towing load.
  • This mount fits standard 2-inch square receiver tubes only. It is not compatible with 1-1/4-inch or 2-1/2-inch receiver tubes without an adapter (adapters are not included and may affect ratings).
  • Before every tow, verify the correct ball is locked in the active downward position and that the pivot mechanism is fully engaged. Towing with the head unlocked is unsafe.
  • Do not use this mount for weight-distribution hitch systems -- it is a standard ball mount and does not accept weight-distribution spring bars.
  • This product is not a gooseneck ball or fifth-wheel hitch. It does not replace a bed-mounted fifth-wheel or gooseneck system.
  • Inspect the shank, pivot pin, balls, and hardware before each season and after any heavy-use towing period. Replace if cracked, bent, or showing significant corrosion.
