1000W Xantrex PRO Series modified sine wave inverter for RV and marine power systems. Converts 12V DC battery power to 120V AC power and includes a built-in transfer switch, detachable digital remote, GFCI receptacle option, and hardwire terminal strip installation flexibility.
The Xantrex 806-1010 PRO XM1000 is a 1000 watt 12V DC to 120V AC inverter designed for RV and marine electrical systems that need reliable onboard AC power from a battery bank. It is suited for powering many common electronics and small appliances when shore power or generator power is not available.
The PRO XM1000 includes a built-in transfer switch that automatically detects shore power or generator power and transfers loads as power availability changes. It also includes a detachable digital remote display that shows inverter status, AC source information, and battery voltage from a more convenient mounting location.
Converts 12V DC battery power into 120V AC power for compatible RV and marine loads
Automatically transfers between inverter power and incoming shore/generator power
Digital remote displays AC source, battery voltage, and inverter power information
UL 458 and FCC Class B design for demanding mobile power environments
The PRO XM1000 is commonly used in RV and marine systems where an existing battery charger, converter, or generator is already installed and the user needs inverter power for selected AC loads. Common loads may include TVs, small electronics, chargers, entertainment equipment, and other compatible devices within the inverter's power rating.
• One Xantrex 806-1010 PRO XM1000 inverter • Detachable digital remote display • GFCI receptacle connection option • Built-in transfer switch and AC pass-through protection
The PRO XM1000 is designed for hardwire installation using a terminal strip or by connecting AC through the included GFCI receptacle. The detachable digital remote can be mounted in a convenient location for system monitoring. Use properly sized DC cables, fusing, and AC wiring for the installation. Follow the Xantrex owner’s guide and applicable RV, marine, and electrical code requirements.
This PRO XM1000 model is a modified sine wave inverter. Some sensitive electronics, variable-speed appliances, medical devices, battery chargers, and certain motor-driven loads may require a pure sine wave inverter instead. If your application specifically requires pure sine wave output, verify the correct Xantrex pure sine model before ordering.
The Xantrex 806-1010 PRO XM1000 is a 1000W 12V DC to 120V AC modified sine wave inverter with a built-in transfer switch, detachable digital remote, AC pass-through protection, and RV/marine-rated design features.
