Eliminates "Tail Wagging the Dog". Heavy-gauge steel. Powder coated. No drilling required.
The SuperSteer SS302 W20/W22/W24 Rear Trac Bar will put an end to the "tail wagging the dog" sensation or oversteer and deeply improve stability. Almost every RVer has experienced that uneasy feeling when the steering wheel is turned suddenly - a swinging motion that threatens control over the vehicle. The SS302 rear trac bar eliminates that uncomfortable sensation, greatly improving stability, driver control and safety. These suspension stabilizers eliminate unwanted and uncontrolled side shift of the rear axle, helping to stop the push-pull effect from passing trucks and crosswinds. Locates the rear axle to prevent lateral motion.
Workhorse W Series Class A Motorhome Chassis: • Workhorse W20 (2001-2009) - Gas • Workhorse W20D (2009-2010) - Diesel • Workhorse W22 (2001-2009) • Workhorse W24 (2004-2008) GVWR Rating: 20,000-24,000 lbs Rear Differential: Dana 110, 130, or 150 Motorhome chassis manufacturers use different rear axles for different weight ratings. This part is designed to fit the Workhorse "W" Series chassis with a 20,000-24,000 lb GVWR using a Dana 110, 130, or 150 rear differential. Workhorse made a limited number of "W20D" diesel chassis on the 20,000 lb chassis from 2009-2010. The SS302 rear trac bar fits both gas and diesel model chassis.
Package Includes: • (1) SuperSteer SS302 Rear Trac Bar • Polyurethane Bushings • All Mounting Hardware (Bolts) • Installation Instructions
Download the SuperSteer SS302 Rear Trac Bar Installation InstructionsInstallation Time: Approximately 1.5 hours. Easy installation using OEM holes - no drilling required. Comes with polyurethane bushings and all mounting hardware. Complete installation instructions included with product. The trac bar attaches at one end to the frame and the other to the rear axle, preventing side-to-side motion.
